Computerized Servo Tension and Compression Universal Testing Machine 500 KN Lab Equipment Price WDW-500E
It is applicable for wide range of material for tension, compression, bending, shearing and low cycle test. Suitable for metal, rubber, plastic, spring, textile, and components testing. It is widely used in the corresponding industries, research and development, test institutes and training centers etc.
Standards
ASTMA370,ASTME4,ASTME8,ASTME9,ISO6892,ISO7438,ISO7500-1,EN10002-4,GB/T228-2002,etc.
1.Adopt floor structure,High Stiffness, lower for tensile, upper for compression,upper for tensile,
lower for compression, double space. The beam is step less lifting.
2. Adopting ball screw drive, realize no clearance transmission,make sure the precision control of
the test force and deformation speed.
3.The shiel plate with limit mechanism used to control the beam moving range, in order to avoid
sensor damaged due to the moving distance is too large.
4.The table, moving beams is made of high quality precision machining steel plate , not only
reduce the vibration generated by specimen fracture, but also improve the stiffness.
5.Three columns of mandatory orientation, make the main unit rigidity much improved, to further
ensure the repeatability of measurement.
6.Adopt bolt type grip installation, make the grip replace easier.
7.Adopt AC servo driver and AC servo motor, with stable performance,more reliable. Have
over-current, over-voltage, over speed, overload protection device.
|
Model |
WDW-500E |
|
Max. Load |
500 KN |
|
Structure |
Four-column Floor Model (Upper Is Compression And Lower Is Tensile) |
|
Control Method |
Computer Automatic Control |
|
Load Accuracy |
0.5 Class |
|
Load Range |
0.2%~100% FS (1KN~500KN) |
|
Motor |
Panasonic Motor, Made In Japan |
|
Sensor |
Import Sensor, Made In USA |
|
Resolution |
1/300000 |
|
Measuring Range Of Deformation |
2%~100% |
|
Accuracy Indication Of Deformation |
≤±0.5% |
|
Disp. Indicating Relative Error |
≤±1% |
|
Displacement Resolution |
0.04um |
|
Adjusting Range Of Control Rate Of Load |
0.005~5%FS/S |
|
Control Precision Of Control Rate Of Load |
When rate < 0.05% FS/s, the precision is within ± 2% of setting value; When rate ≥ 0.005%FS/s, the precision is within ± 1% of setting value. |
|
Adjustment Scope Of Deformation Rate |
0.005~5%FN/S |
|
Accuracy Of Deformation Rate |
Test Speed<0.05%FN/s, within the ±2% of the preset value, Test Speed≥0.05%FN/s, within the ±0.5% of the preset value. |
|
Adjusting Range Of Displacement Rate |
0.05~200mm/min (Can be customized) |
|
Control Precision Of Displacement Rate |
When rate < 0.5mm/min, within ± 1% of setting value; When rate ≥ 0.5mm/min, within ± 0.5% of setting value. |
|
Scope Of The Consistent Load Deformation And Displacement Control |
0.5%~100%FS |
|
Accuracy Of The Consistent Load |
Preset value≥10%FN, within the ±0.1% of preset value; Preset value<10%FN, within the ±1% of preset value. |
|
Tensile Space |
700mm (Can be customized) |
|
Compression Space |
700mm (Can be customized) |
|
Effective Spacing |
650mm (Can be customized) |
|
Load Cell Configuration |
One PC (Max Load). More load cells can be added according to customer requirement. |
|
Extend Configuration |
Large deformation extensometer, High or low temperature test chamber, High temperature oven. |
|
Power Supply |
AC220V±10%,50Hz (Can be customized) |
|
Grips |
Hydraulic Automatic Grips |
|
Dimension |
1360*1000*2830mm |
|
Weight |
3100 KG |
Additional information
| Use |
Plastic Testing Machine ,Tensile Testing Machine ,Compression Testing Machine ,Strength Testing Machine ,Leather Testing Instrument ,Universal Testing Machine |
|---|
