SKZ1041B Liquid Laboratory Equipment High Performance Portable Turbidity Meter Turbidimeter
$4,379.80
Guaranteed Safe Checkout
Features & Compatibility
Principle:
Turbidity, also called turbidity of water or transparent liquid. Caused by light scattering of insoluble suspended matter and
colloidal substances in the water or clear liquid, ISO standard unit of measurement used FTU (turbidity units), FTU and NTU (turbidity units) consistent. When light irradiated to the surface, the incident light, transmitted light, scattered light and the ratio between water turbidity of a certain relationship, By measuring the transmitted light, scattered light and incident light or transmitted light and scattered light to determine the
ratio of the turbidity of water samples.
Features:
1. Streamlined, lightweight design, simple operation and cost-effective
2. Large-screen LCD digital clear display, low drift, high precision circuitry
3. Reliable structure and high precision optical systems, instruments long time stability
4. Chrominance compensation, effectively avoid the interference caused by the sample color, turbidity can accurately reflect
5. Long-life high-intensity light source, no replacement worries, 30 seconds warm-up time to work
|
Light source
|
Tungsten halogen lamp 6V, 12W
|
|
Receiving elements
|
silicon photovoltaic cells
|
|
Measuring range NTU
|
automatic range switching
|
|
0.00 – 50.0, 50.1 – 200 (A type)
|
|
|
0.00 – 50.0, 50.1 – 200,201 – 2000 (B type)
|
|
|
Readings method
|
LCD touch digital display
|
|
Indication error
|
0-200NTU: not more than ± 8% (A type)
|
|
201-2000NTU: not more than ± 6% (B type)
|
|
|
Indication stability
|
≤ ± 0.3% FS
|
|
Zero drift
|
≤ ± 1% FS
|
|
Sample vial
|
φ25mm × 95 mm
|
|
Sample volume
|
20ml ~ 30ml
|
|
Power
|
220 V ± 22V, 50 Hz ± 1Hz
|
|
Dimensions
|
358mm × 323mm × 160mm
|
|
Weight
|
8kg
|
Additional information
| model number |
SKZ1041 |
|---|
